Power contactor ZJW 400A 12V 24V 36V 48V 72V

KL-3030470
Hover on image to enlarge
In stock
122
Ask a question
+

Description

Power contactor ZJW 400A 12V 24V 36V 48V 72V

20 +/- 5C max. Cold running voltage (VDC)
Trip voltage
= 70%
Voltage drop 5% -30%
Mechanical life (min.) 100,000 operations Life
electrical parts (min.) 50,000 operations

Ratings
coils Maximum coil current at rated voltage 0.1 A
At 20 +/- 5C max. Starting coil cold current

Specification:
insulation resistance 100 MΩ min.
Dielectric strength between contacts 2000VAC.
Between coil and contacts 1500VAC.
Ambient temperature and attitude -40C - / + 85C; 0-20000 m
Max.
